Part Number	Rated  Voltage (DC)	Rated  Current (A)	Breaking  Capacity (A)¹	Typical Cold  Resistance (mOhms)²	Typical  Voltage Drop (mV)	Typical  Pre-Arcing I²t (A²Sec)³	Alpha Mark
06 100.0.25	32V	0.250	50A	3250	893	0.00042	D
06 100.0.375	32V	0.375	50A	1310	587	0.00093	E
06 100.0.5	32V	0.500	50A	1070	582	0.001	F
06 100.0.75	32V	0.750	50A	470	427	0.009	G
06 100.1	32V	1	50A	300	345	0.011	B
06 100.1.5	32V	1.5	50A	150	270	0.045	H
06 100.2	32V	2	50A	72	160	0.115	K
06 100.2.5	32V	2.5	50A	52	145	0.14	L
06 100.3	32V	3	50A	35	130	0.21	O
06 100.3.5	32V	3.5	50A	23.8	130	0.5	R
06 100.4	32V	4	50A	21	120	0.56	S
06 100.5	32V	5	50A	14	110	1.2	T
06 100.6	32V	6	50A	8.5	110	1.7	V
06 100.7	32V	7	50A	7.3	80	2.3	X
06 100.8	32V	8	50A	5.1	75	3	Z
